Features and Specifications:

•DMX:2x shielded&gold plated 3-pin XLR(female)

•Network:1*10/100 Mbps RJ45 connector
•Power supply:9-12V DC
•Support Agreement:DMX512,RDM(selected)ANSI E1.20
•DMX port direction:input or outputconfigurable)
•DMX port protection:built-in 1.5kv
•DMX Port Match/Offset:yes
•DMX Parameters:Frame Frequency:10-40fps/Break:176-352μs
•Support agreement:Art-Net,UDP,TCP,ICMP,DHCP
•Port rate:10/100Base TX
•Port datection:auto-negotiation,MDI/MDIX
•Configuration management software:search found
•WEB configuration:support
•Ethernet port indication:connection and activity
•Run:LED indication
•Weight:260g
•Size: 11*9*5cm
