Features and Specifications:

•RDM E1.20 compliant

•1 input to 6 outputs
•3pin & 5pin DMX In
•3pin & 5pin DMX Thru
•3pin & 5pin DMX Out
•100% isolation for all inputs and outputs
•Signal & power LED indicator for output
•Boost/repeat RDM/DMX signals
•Regenerate/clean RDM/DMX signals
•Split RDM/DMX signals and build star topologies
•Connect a large number of fixtures to a single universe
•Prevent reflection on signal lines
•Rack or Truss mounting
•Power input: AC 110V or 230V
•Size: 482 x 147 x 44 mm (1U rack mount)
•Weight: 1.8 kg
