Features and Specifications:

• Unit size: 120 X 110 X 160 mm

• Unit weight: 1.7kg
• Voltage: AC 110-120V/60Hz, AC 220-240V/ 50Hz
• With high speed CPU memory do the mathematic operatation .
• LCD display.
• DMX addresss can be set between 001-512.
• With memory function .
• 3 pin male XLR socket for DMX input .
• Two control curves are available: SWITCH,LINER
• Each channel independent and has linear dimming from
   0-100%,with memory function
• Power failure protection, phase correction ,
  DMX signal parallel , use it alone
• Rating current for every channel 10A-20A ,250V 5X20MM
